ECUMaster Printed Flying Lead Harness for EMU Black

The Printed Flying Lead Harness for ECUMaster EMU Black is the ideal starting point for a custom EMU Black installation. Whether you're wiring a unique engine combination or replacing an existing harness, this 3-meter harness provides a clean, professional foundation for your project.

It features 59 labeled wires with terminals installed, plus 2 shielded motorsport-grade twisted pair cables for critical signal circuits. Each wire is printed with its corresponding channel name to simplify installation, reduce wiring errors, and save time during assembly.

Constructed using FLRY-B wire—the German DIN standard for automotive wire, comparable to SAE TXL automotive wire. The harness uses metric conductor sizes roughly equivalent to 22 AWG through 17 AWG. Each wire is sized according to its intended function, with smaller conductors for low-current signal circuits and larger conductors for higher-current connections.

Full Harness Specification
